Cayin A-50T EH Version EL34EH/12AX7EH/12AU7EH Vacuum Tube Integrated Amplifier

Cayin A-50T EH Version EL34EH/12AX7EH/12AU7EH Vacuum Tube Integrated Amplifier

Product Price: $998.99 USD
Product Quantity: 5 Units in Stock

Voltage:



Devliery to: Shipping Costs:

Total Price:

Devliery-time: On-time Delivery With (DHL/UPS/EMS) About 7-10 days!

Custom taxes: All product not include taxes, But we can declare low values as your wish!

Payment:

Buyer Protection

  • Full Refund , if you don't receive your order or sold out
Declaration
Features:
1. Pure handmade
2. Bias testing points and regulators added on the top side
3. Two special handmade wide frequency response EI audio transformers
4. Special handmade low magnetic leakage toroidal power transformer
5. 12AX7EH x 2 and 12AU7EH x 2 for preamp
6. The power amplification uses EL34EH x 4 for class AB1 push-pull power amplifier.
7. EGG silicon cores, high-purer 4N winding wire
8. Special interlocked winding coiling process
9. High end Nichicon capacitors and audio choke coil
10. Silver plated high purity copper internal signal wiring
11. All point to point wiring (hand soldering)
12. High quality Japan ALPS volume control plus headphone output
13. 4Ω / 8Ω / selectable output load impedance
14. Removable metallic tube protection cage included

Specifications:
Output Power: 18W+18W (RMS Triode mode) 38W+38W (RMS Ultralinear mode)
Frequency Response: 8Hz~50kHz (-3dB)
Harmonic Distortion: 1% (1kHz)
Output Impedance: 4Ω, 8Ω
Input Impedance: 100kΩ
SNR: 90dB
Input Sensitivity: 300mV
Supply Voltage: ~220V±5% 50Hz
Power Consumption: 280W
Tube: 12AX7EH x 2, 12AU7EH x 2, EL34EH x 4
Input Interface: 4 sets of RCA
Volume: 350x300x185 mm
Net Weight: 13KG
Weight:15KG
